Modifying an SNAT Rule

Scenarios

After an SNAT rule is added, you can modify parameters in the SNAT rule as required.

Note that modifying an SNAT rule may interrupt your services.

Prerequisites

An SNAT rule has been added.

Procedure

  1. Log in to the management console.

  2. Click image1 in the upper left corner and select the desired region and project.

  3. In the upper left corner of the page, click image2 to expand the service list and choose Network > NAT Gateway.

    The Public NAT Gateways page is displayed.

  4. Click the name of the public NAT gateway.

  5. On the SNAT Rules tab, locate the SNAT rule you want to modify.

  6. Click Modify in the Operation column.

  7. In the displayed dialog box, modify type of the public IP address or description.

    **Figure 1** Modify SNAT Rule

    Figure 1 Modify SNAT Rule

  8. Click OK.
